Tilton Racing 72-791 Front Engine Throttle Linkage System For 72-603 72-615 72-803 72-903

Tilton's 72-791 throttle linkage kit includes a bearing carrier block that bolts to the existing holes on the pedal assembly frame. It also includes adjustable 1/4" heim joints that connect to the gas pedal. The V shaped cam has a plethora of holes allowing you to use it as a 1:1 ratio or more like a cantilever. This setup was designed specifically for front engine vehicles with a pull type throttle cable.

Works With:

72-615 Swinging throttle pedal

72-603 Floor mount brake, clutch and throttle assembly

72-803 Floor mount brake, clutch and throttle assembly

72-903 Floor mount brake, clutch and throttle assembly

You'll use a 1/4" pin clevis (not included) to connect a Morse style push/pull cable to the linkage. The clevis pin will be 1/4" but the threads need to be 10-32 for the cable to thread into.

Tilton makes a billet aluminum clevis part number 72-797 or we also sell an economy steel clevis that works just fine.
