Klixon 3TC Series 3TC7-30 Push Button 30 Amp Push To Reset Circuit Breaker With #8 Screw Terminals
California Prop 65 Warning: This item may cause cancer or reproductive harm. For more info visit p65warnings.ca.gov
Description
3TC Series Aircraft Circuit Breaker
Klixon has historically set the standard for Aerospace circuit breakers. 3TC breakers represent state of the art protection for today's aerospace power systems. Their light weight and small size make them especially well suited for offroad racing, aircraft, avionics, electrical systems, communication systems and defense vehicles.- Fits a 7/16" hole in your dash
- Miniature size
- Light weight
- Trip–free design
- High vibration resistance
- High interrupting capacity
- Coordinated ratings
- AS58091 qualified
- Typical end use: Offroad racing and Aircraft power distribution systems where ambient temperature exceeds the 160°F (71°C) maximum of non–ambient compensated thermal circuit breakers
Features
- Vibrations: 10G minimum, 50–500 Hz
- Mechanical Shock: 50G
- Acceleration: 10G
- Weight: 36 gram maximum (3TC14)
- Interrupt Current 15–35 amps: 6,000 amps at 28 VDC
- Endurance 2,500 cycles: 120 VAC, 400 Hz inductive
Specifications
15–35: 2,000 amps at 120 VAC, 400 Hz
25 amps: 1,800 amps at 120 VAC, 400 Hz
5,000 cycles: 120 VAC, 400 Hz resistive
2,500 cycles: 30 VDC inductive
5,000 cycles: 30 VDC resistive
10,000 cycles: Mechanical, no load
