Peterson Fluid Systems 09-1584 Two Bolt Mounting Bracket For Their Oil Primer Pumps And Filter Mount
Closeout price. All sales are final.
Estimate Shipping
Price: $57.99
1 in stock
Sold As:
1 Bracket
Part Number: PET091584
MFG Number:
09-1584
California Prop 65 Warning: This item may cause cancer or reproductive harm. For more info visit p65warnings.ca.gov The above image is a representation of this item. Actual item may vary. If it's crucial to what you're working on, call the store at 951-737-RACE, and one of our sales reps will be happy to email you a current photograph. Product Information:
Peterson's remote mounting bracket is machined from 6061 Aircraft grade aluminum. It provides a secure flange for your remote oil filter mount or dry sump engine oil primer pump (shown only for reference).
There are two 1/8" dowel pins that index into the back of Peterson's remote oil filter mounts. Then it uses a single 3/8" bolt to hold them together. This design allows you to mount the above flange in any direction while still keeping the remote oil filter or primer pump level.
The two mounting holes are 3/8" and spaced 3" on center. This flange will also work with our KTK04121 mounting tab listed below.
There are two 1/8" dowel pins that index into the back of Peterson's remote oil filter mounts. Then it uses a single 3/8" bolt to hold them together. This design allows you to mount the above flange in any direction while still keeping the remote oil filter or primer pump level.
The two mounting holes are 3/8" and spaced 3" on center. This flange will also work with our KTK04121 mounting tab listed below.
