Blue Sea Systems Split 12 Circuit ATO Blade Fuse Block With Neg Bus 100A Max Per Block 30A Per Cir

Blue Sea Systems Split 12 Circuit ATO Blade Fuse Block With Neg Bus 100A Max Per Block 30A Per Cir
Rough Shipping Estimate
Estimate Shipping
Price: $62.99
In Stock
Sold As: 1 Fuse Box With Cover

Part Number: BSS5032

MFG Number: 5032


Order this item to pickup at our Corona, CA store. You'll pay when you get here. You can pay by credit card, cash or PayPal and we'll contact you when this order is ready for pickup.


California proposition 65 warningCalifornia Prop 65 Warning: This item may cause cancer or reproductive harm. For more info visit p65warnings.ca.gov

Description

Blue Sea Systems 5032 fuse box wiring diagram

Blue Sea System's 5032 ST Split Blade Fuse Block: 6 Positive + 6 Positive Independent Circuits with negative bus and cover

    Features:
  • Split Bus Fuse Block with ground for use when a mix of switched and 24-hour circuits are desired in the same block
  • Provides two isolated groups of six ATO/ATC circuits
  • For use with either two isolated batteries or with a single battery providing a mix of 24 hour and switched circuits
  • Screw terminals for securing wires accept ring terminals
  • One-piece stainless flange nuts ensure safe and secure connections
  • Clear insulating cover with label recesses and storage for two fuses, satisfies ABYC/USCG insulation requirements
  • Easy to open, push button latch for easy access to fuses
  • Tin-plated copper buses and fuse clips
  • Fuses sold separately
    Specifications:
  • Circuits: 12
  • Maximum Amperage: 30A per circuit 100A total [not to exceed 80A per load group]
  • Maximum Voltage: 32V DC
  • Mounting: #8 Screw (M4)
  • Negative Bus: #10-32 Stud
  • Recommended Torque: 24 in-lb (2.71 N·m)
  • Screw Terminal Type: #8-32 Screws with captive star lock washer
