Blue Sea Systems 12 Circuit ATO Blade Fuse Block With Cover 100A Max Per Block 30A Max Per Circuit

Blue Sea Systems 12 Circuit ATO Blade Fuse Block With Cover 100A Max Per Block 30A Max Per Circuit
Rough Shipping Estimate
Estimate Shipping
Price: $43.99
In Stock
Sold As: 1 Fuse Box With Cover

Part Number: BSS5029

MFG Number: 5029


Order this item to pickup at our Corona, CA store. You'll pay when you get here. You can pay by credit card, cash or PayPal and we'll contact you when this order is ready for pickup.


California proposition 65 warningCalifornia Prop 65 Warning: This item may cause cancer or reproductive harm. For more info visit p65warnings.ca.gov

Description

Blue Sea Systems 5029 fuse box wiring diagram

Blue Sea System's 5029 and 5034 ST Blade Fuse Block - 12 Circuit With Cover

Features:
  • Consolidates branch circuits and in-line fuses
  • Positive distribution bus with #10-32 stud
  • Can be used for 24-hour circuits
  • Models available with or without a cover
  • Cover satisfies ABYC/USCG requirements for insulation, incorporates an easy to open push button latch providing easy access to fuses, storage for two spare fuses, and label recesses that accept Blue Sea Systems" Small Format Labels for circuit identification
  • Fuse blocks with covers include 20 write-on circuit labels
  • Tin-plated copper buses and fuse clips
  • Accepts ring or snap fork type terminals
  • Accepts ATO and ATC fast acting blade fuses
  • Fuses sold separately
Specifications:
  • Circuits: 12
  • Maximum Amperage: 100A per block 30A per circuit
  • Maximum Voltage: 32V DC
  • Mounting: #8 Screw (M4)
  • Positive Bus: #10-32 Stud
  • Recommended Torque: 24 in-lb (2.71 N·m)
  • Screw Terminal Type: #8-32 Screws with captive star lock washer
  • Weight: 0.68lb (0.31 kg)
