XRP Black Cloth Braided High Pressure AN -6 Power Steering Hose 5/16" Inside Dia. 11/16" Outside Dia
Estimate Shipping
Price: $7.43
14 in stock
Sold As:
Priced Per Foot
Part Number: XRP519006
MFG Number:
519006
California Prop 65 Warning: This item may cause cancer or reproductive harm. For more info visit p65warnings.ca.gov The above image is a representation of this item. Actual item may vary. If it's crucial to what you're working on, call the store at 951-737-RACE, and one of our sales reps will be happy to email you a current photograph. Product Information:
There are no refunds on hose once we cut it for you.
This hydraulic hose is commonly used on Fox 2.0" x 7/8" shaft shocks as a reservoir line. This premium quality power steering hose is made of synthetic rubber tube, polyester inner braid with single wire braid reinforcement and polyester braid cover. Operating temperature is between -55°F and +300°F (except air +250°F). Suitable for many applications: air, gasoline, fuel and lubricants, over-the-wall air tools, etc.
For a Fox 2.0" shock that has a 7/8" shaft, you'll use 9/16" ORB fittings and the steel -6 hose ends listed below.
Technical Specifications
Size: #6
Working Pressure: 2,250psi
Burst Pressure: 9,000psi
Weight Per Foot: 0.23 lbs
Minimum Bend Radius: 4.0"
Size: #6
Working Pressure: 2,250psi
Burst Pressure: 9,000psi
Weight Per Foot: 0.23 lbs
Minimum Bend Radius: 4.0"
