Fox Shocks 010-00-032 Press Fit Rubber Air Valve Pellet Retainer Uses 010-00-000-A Rubber Pellet

Estimate Shipping
Price: $3.00
98 in stock
Sold As:
1 Retainer
Part Number: FOX01000032
MFG Number:
010-00-032
California Prop 65 Warning: This item may cause cancer or reproductive harm. For more info visit p65warnings.ca.gov The above image is a representation of this item. Actual item may vary. If it's crucial to what you're working on, call the store at 951.737.RACE, and one of our sales reps will be happy to email you a current photograph. Product Information:
This press-fit retainer was usually found on Fox Performance Series shocks before Fox switched over to the 10-24 allen plug. If you have the style of shock that you fill with a long needle tool (see photo), then inside the shock body, at the very top of the body, you'll see this retainer.
People would thread a wood screw into the bottom of the retainer and use a slide hammer to pull it out of the shock body. Pressing it back into the shock body is way more difficult.
People would thread a wood screw into the bottom of the retainer and use a slide hammer to pull it out of the shock body. Pressing it back into the shock body is way more difficult.
Fox also used this retainer inside 226-00-095 reservoir end caps on UTV shocks. If you have a stepped reservoir with an end cap that looks like this, this is what the inside of it looks like. You use a short needle valve with that end cap. Or if you're sick of the needle fill tool and want to use a Schrader valve instead, you can purchase the 226-00-095 cap and drill and tap it for 1/8" NPT pipe thread and thread a 1/8" Schrader valve into it.
